WPM series High Voltage Pulse Capacitor

Features:
Non-magnetic stainless steel shell, high specific energy
Dry-type fully sealed structure avoids environmental pollution due to leakage, safe and reliable, and has good moisture-proof performance
Good self-healing property, stable performance, safe and reliable long life
Contact Us PDF Download

Share:

PREV：WPR series High Voltage Filter/Resonat CapacitorNEXT：WPH seires High Voltage Pulse Capacitor
Typical Applications:
In the energy repository as the main energy storage element
Impulse current generator, impulse voltage generator, discontinuous pulse device
Cable tester, mineral exploration instrument, nano equipment, etc.

Specifications

Rated DC Voltage 4kV~75kV
Normal capacitance 1μF～10000μF
Capacitance Tolerance 0~10% or ±5 %（J） ±10 %（K）
Loss Tangent ≤0.0020（100 Hz, 20 ℃）
Operating temperature range -25 ℃～50 ℃
Voltage Test Between Terminals 1.0UN~1.5UN 10S

Dimensions(mm)

μF Capacitance

kVdc Rated voltage

kJ
Stored energy

kA  Peak current

Reverse
voltage  rate

nH

Inductance

Life  (times)

(△C/C<5%)

J/cm³ Density of

stored energy

mm

Dimensions

kg Weight

1000

5

12.5

35

10

400

5×10

0.8

315×130×380

16

4000

5.5

60

100

10

300

1×104

1.0

425×258×550

58

7500

6.5

158

175

10

150

1×103

1.8

406×305×725

85

75

8

2.4

9.5

90

300

5×10

0.48

256×70×280

6

320

8

10.24

28

80

100

5×104

0.49

256×256×320

22

500

10

25

35

20

200

1×104

1.04

265×256×355

25

500

10

25

35

20

200

5×104

0.8

290×256×420

30

500

10

25

30

20

200

2×103

1.63

278×187×295

20

1000

10

50

75

10

100

5×104

0.85

480×256×479

62

500

11.2

31.36

30

10

200

2×104

1.01

290×256×420

31

830

11.2

52.06

75

10

80

2×104

1.0

440×420×280

68

600

15

67.5

75

20

165

5×104

0.7

430×406×550

90

70

20

14

10

20

300

10×104

0.53

405×205×320

26

140

20

28

20

20

150

5×104

0.57

390×258×485

47

55

25

17.2

6

10

400

10×104

0.52

340×134×730

32

110

25

34.4

10

10

240

10×104

0.52

429×258×595

60

145

25

45.3

20

10

200

2×104

0.91

358×318×438

57

254

35

155.58

40

10

75

4×104

0.8

740×385×680

175

80

60

144

40

10

150

4×104

0.83

510×500×680

155
